Markator FlyMarker® PRO STATION

  • Compact table marking system with electromagnetic driven marking pin
  • Marking area (x/y) 75 x 25 mm, 75 x 45 mm,
    120 x 25 mm or 120 x 45 mm
  • Alternatively all versions of the FlyMarker PRO are available in the touch version
  • High resolution LC-colour display and control unit in break-proof housing
  • Integrated keyboard
  • Interfaces: USB-A, USB-B and Ethernet
  • High quality, double guided linear guides for precise marking results
  • Latest software technology
  • Marking preview to check the marking file before the marking process
  • Axial-, radial- and circle marking and marking of Data Matrix Codes
  • Internal memory for several hundred marking files, fonts and logos
  • Different marking forces can be chosen
  • Extremely deep markings possible due to optional available magnet
  • Illuminated marking area
  • No external control unit neccessary

Download brochure

Marking area (x/y)
75 x 25 mm, 120 x 25 mm,
75 x 45 mm or 120 x 45 mm

Available character heights
1,0 to 24,9 mm or 1,0 to 44,9 mm

Fonts
Medium spaced lettering similar to DIN 1451 in single dot characters (size 5 x 7 or 9 x 13)

Drive of the marking pin
Electromagnetic

Available characters
Figures 0 - 9
Capital letters A - Z
Small letters a-z
Various punctuation marks e.g. . ; / , etc.

Interfaces
USB-A, USB-B, Ethernet

Height compensation
up to max. 5 mm (constant marking depth also on uneven surfaces)

Weight
4,2 kg

Resolution of the stepping motors
0,05 mm
